- Size: 3
- Place of Origin: CHINA
- Brand Name: HRJ
- Model Number: WDSC-300/500/600
1.Introduction
Used in mechanical property test of tensile stress relaxation at ambient temperature for metallic materials, such as strand, PC steel rod and steel wire;
Satisfy with relative requirements of GB/T10120-1996 Metal Stress Relaxation Test Method and ASTM E328-2008 Test Method of Stress Relaxation for Material and Structure;
standard strand,indented strand,compact strand,Epoxy resin steel strand,PC Strand,unbonded steel strand or monostrand,galvanized,,messenger wire)、拉线(guy wire,core wire or strength member,earth wire/ground wire,barrier cable,structure cable.
Steel Bars for Prestressed Concrete,plain bar,helical grooved bar,helical ribbed bar,ribbed bar.ISO 6934-3:1991 Steel for prestressing of concrete-Part 3:Quenched and tempered wire
- Size: 3
- Place of Origin: CHINA
- Brand Name: HRJ
- Model Number: WDSC-300/500/600
2.Technical Specifications
Rated load: 300/500/600kN;
Measuring range of load: 1%-100% of full range;
Load accuracy: ≤±1%;
moving speed: 0.001-50mm/min;
loading rate: 100-5000N/S;
deformation resolution: 0.001mm;
tensile stroke: 0-200mm;
specimen size: Φ9.50, Φ11.10, Φ12.70, Φ15.24, Φ18.00, Φ22.00
Nominal tensile length: 800-1000mm;
Power: 220VAC, 50Hz/2.0kW/4.5kW;
Dimension (L*W*H): 2840*700*990mm/3600x760x1080mm
