- Place of Origin: china
- Brand Name: HRJ
- Model Number: WDW-LQ
- Weight: 800.000 kg
Technical Specification
1) max. test force: 2kN,5kN,10kN,20kN,50kN,100kN,200kN,300kN,500kN,600kN
2) measuring range of test force: 1/±300000 of full scale
3) relative error of indicating value: ±1%
4)stroke of crosshead at room temperature: 1000mm
5) stroke of crosshead at high/low temperature: 650mm
6) moving speed of crosshead: 0.005---500mm/min
7) test space (W*D):1100*600mm
8) working voltage: 220VAC/50Hz
9) working voltage of environment test chamber: 380VAC/50Hz
10) overall dimension of loading machine (L*W*H):1100*2100*2450mm
- Place of Origin: china
- Brand Name: HRJ
- Model Number: WDW-LQ
- Weight: 800.000 kg
Low temperature environmental test chamber
1)working temperature: -100°C-room temperature
2) inner size (W*L*D): 300*900*300mm
3) overall dimension (W*L*D):500*1100*500mm
4) cooling mode: cooled by liquid nitrogen spray
Technical Specification
1)working temperature: 200-900℃
2)long-time working temperature: 800℃
3)Heating component: FeCrAl resistance wire
4)diameter of heating wire: Φ1.5mm
5)temperature element: K-type temperature thermocouple (including special compensation lead)
6)even heat area length: 100mm
7)measuring range segments: three-step control
8)measuring points of heat: 3
9) inner dimension of furnace(Dia×L).: Ф90×300mm
10) overall dimension of furnace(Dia×L): Ф320*380mm
11) working power: 380V
12) Power: limit power 5KW
